US Navy Seal DXF File

IN Metal Art

Description

The US Navy Seal DXF file is intended to be cut from metal using a CNC cutting system. Once fabricated, this artwork can bring a patriotic, naval feel to a study or office. This artwork features the Seal of the United States Department of the Navy which depicts a bald eagle standing on an anchor in front of a shipping vessel.

Machinist Notes

The Eagle DXF file has been reviewed and tested by a machinist for compatibility with various CNC systems. This design can be easily modified with CAD software. Review the tables below for more detailed specifications.

Specifications for Plasma Compatible Files

Dimensions (inches) 18.31" x 17.6"
Nodes 1363
Cut Length (inches) 467.01"
Est. Cut time 5.84 minutes
(assuming 80 inches per minute)


Specifications for Laser and Waterjet Compatible Files

Dimensions (inches) 18.31" x 17.6"
Nodes 2197
Cut Length (inches) 692.58"
Est. Cut time 8.66 minutes
(assuming 80 inches per minute)
(SKU: 00963-A)

License

All artwork on DesignShop comes with the Fabricators License. The license agreement gives you the right to use any artwork purchased on DesignShop to produce physical goods for personal or commercial project for yourself or a client. The license agreement specifically prohibits you from sharing or redistributing the digital files. If you have any questions, you can read the entire license agreement here.

Download for 1 Credit


Pro members get this for $8.00. Or buy for $ 49.00 without a membership.
SKU: 00963-A
Machines: Machines, Plasma CNC, Laser CNC, Water jet CNC

Quality Guarantee

Our cut-ready designs are tested to ensure they'll work great with your plasma, waterjet, or laser cutting system.
